Standards | IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
---|
WiFi Generation | Wi-Fi 6 |
---|
Wireless Standard | IEEE 802.11a / IEEE 802.11ac / IEEE 802.11ax / IEEE 802.11b / IEEE 802.11g / IEEE 802.11n |
---|
Security | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
---|
WPA | WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x) |
---|
WAN Ports | 1 x 10/100/1000M |
---|
LAN Ports | 4 x 10/100/1000M |
---|
Buttons | WPS/Wi-Fi Button Power On/Off Button LED On/Off Button Reset Button |
---|
Wireless Data Rates | 5 GHz: 1201 Mbps (802.11ax) 2.4 GHz: 574 Mbps (802.11ax) |
---|
Frequency Band | 2.4 GHz / 5 GHz |
---|
Antenna | 4 x Fixed High-Performance Antennas |
---|
Transmitted Power | CE: <20dBm(2.4 GHz) <23dBm(5.15 GHz~5.25 GHz) FCC: <30dBm(2.4 GHz & 5.15 GHz~5.825 GHz) |
---|
Operation Mode | Access Point Mode / Wireless Router Mode |
---|
Interface | USB 2.0 |
---|
VPN support | PPTP, OpenVPN |
---|
Power Supply | 12 V, 1.5 A |
---|
System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
---|
Dimensions | 10.20" x 5.30" x 1.50" |
---|
Temperature | Operating Temperature: 0°C~40°C (32°F ~104°F) Storage Temperature: -40°C~70°C (-40°F ~158°F) |
---|
Humidity | Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
---|
