Power Consumption: 10.07W / 34.4 Btu/hour Voltage: DC 5.3V Amps: 2A
Features
One USB console controls four DVI computers and two additional USB 2.0 devices Fully compliant built in 2-port USB 2.0 hub. Computer selection via front panel pushbuttons or hotkeys Audio enabled - full bass response 2.1 channel sound Multiplatform support - Windows 2000 / XP / Vista, Linux, Mac, and Sun Superior video quality - 1920 x 1200, 60Hz; DDC2B Independent switching of KVM, USB, and Audio focus DVI digital and analog monitor support - fully compliant with the DVI specifications HDCP compliant Video DynaSync - stores the console monitor's EDID (Extended Display Identification Data) to automatically optimize display resolution and refresh rate Power on detection - if one computer is powered off, the CS1764A will automatically switch to the next powered-on computer Console mouse port emulation/bypass supports multifunction / programmable mice Mac/Sun keyboard support and emulation Auto Scan Mode for monitoring all computers Firmware upgradeable via USB
Dimensions & Weight
Dimensions
10.6" x 3.4" x 2.2"
Weight
2.2 lbs.
Package Contents
Package Contents
1 x CS1764A USB 2.0 DVI KVMP Switch 4 x KVM Cable (DVI-D, USB, Audio; 1.8m/6ft) 1 x Power Adapter 1 x User Instructions
